The Best Sharpening Jig for Chisels and Plane Irons
Researched by Johnny Alto · last updated July 28, 2026
Short answer: The best sharpening jig for chisels and plane irons is the ATLIN Honing Guide. An upgraded Eclipse-style side-clamp guide with a hardened steel roller that will not develop flat spots, and it covers the widths that matter, chisels from 1/8 to 1-7/8 inch and plane irons from 1-3/8 to 3-1/8 inch, with separate jaw positions for low-angle and high-angle tools. The main things to weigh are angle range, roller type, width limits, and it only hones the bevel.
ATLIN Honing Guide
An upgraded Eclipse-style side-clamp guide with a hardened steel roller that will not develop flat spots, and it covers the widths that matter, chisels from 1/8 to 1-7/8 inch and plane irons from 1-3/8 to 3-1/8 inch, with separate jaw positions for low-angle and high-angle tools. It is inexpensive, widely owned, and reference-marked for 25 and 30 degrees. The honest limits: side-clamp guides can rack slightly on very narrow or skewed blades, giving a mildly skewed bevel, blades under 1/8 inch will not seat, and it does not set the angle for you, so you get repeatable angles only if you set blade projection with a stop block every time.
Check price on Amazon Live price on Amazon. Representative image.A honing guide's whole job is to hold a chisel or plane iron at one repeatable angle so you get a flat, consistent bevel instead of a rounded-over mess from freehand wobble. Hand-sharpening is genuinely hard to do consistently, and a 20 to 30 dollar jig removes most of the frustration. This is for someone with waterstones, diamond plates, or sandpaper who wants edges that are actually sharp and repeatable. Here is the buyable pick, the premium options, and what the jig does not do.
How do the best options for sharpening jig for chisels and plane irons compare?
| Pick | Product | Why it makes the list |
|---|---|---|
| Top pick | ATLIN Honing Guide | An upgraded Eclipse-style side-clamp guide with a hardened steel roller that will not develop flat spots, and it covers the widths that matter, chisels from 1/8 to 1-7/8 inch and plane irons from 1-3/8 to 3-1/8 inch, with separate jaw positions for low-angle and high-angle tools. |
| Best premium (direct-buy) | the Katz-Moses Universal Sharpening Jig | Clamps virtually any width and handles skewed and straight blades without add-ons, with built-in angle shelves and a magnetic fence. It is sold on kmtools.com, not Amazon, and costs more than the ATLIN. |
| Best precision (direct-buy) | the Veritas Mk.II Honing Guide | The most precise angle registration, a wide clamping range, and an optional cambered roller for plane irons. It is a Lee Valley product, not on Amazon, pricier, and has more setup fiddliness. |
| Cheapest option | a generic Eclipse-style side-clamp honing guide | The cheapest way to get repeatable bevels. Cheaper clones have softer rollers and looser clamps than the ATLIN, so the ATLIN is usually worth the small premium. |
What should you look for in sharpening jig for chisels and plane irons?
A few things separate a good sharpening jig for chisels and plane irons from a frustrating one: angle range, roller type, width limits, and it only hones the bevel. Weigh these before you buy.
- Angle range: side-clamp guides realistically cover about 25 to 35 degrees by changing blade projection; use a stop block or setup gauge to hit the same angle every time.
- Roller type: a wider roller (ATLIN) is more stable than a narrow one that rocks and rounds the bevel; a cambered roller (Veritas option) is for putting a slight curve on plane irons.
- Width limits: check the jaw range against your narrowest chisel; sub-1/8-inch chisels and some thick Japanese irons can slip.
- It only hones the bevel: after your finest stone you still flatten the back and remove the wire edge on a strop, and a fresh edge is easy to cut yourself on, so wipe away from it.
What the jig does and does not do
A honing guide solves exactly one problem: it holds the blade at a fixed angle so you grind a flat, consistent bevel instead of rocking your hands and rounding it over. It does not set the angle for you, so you still need to project the blade the right distance from the jaws (a stop block or setup gauge makes this repeatable), and it does not touch the flat back of the blade, which you must flatten separately. And after even the finest stone, a tiny wire edge remains that you remove by stropping on leather with compound. Use the jig for the bevel, flatten the back once, and strop to finish, and your chisels will actually be sharp.
What are the best alternatives?
the Katz-Moses Universal Sharpening Jig
Clamps virtually any width and handles skewed and straight blades without add-ons, with built-in angle shelves and a magnetic fence. It is sold on kmtools.com, not Amazon, and costs more than the ATLIN.
the Veritas Mk.II Honing Guide
The most precise angle registration, a wide clamping range, and an optional cambered roller for plane irons. It is a Lee Valley product, not on Amazon, pricier, and has more setup fiddliness.
a generic Eclipse-style side-clamp honing guide
The cheapest way to get repeatable bevels. Cheaper clones have softer rollers and looser clamps than the ATLIN, so the ATLIN is usually worth the small premium.
Bottom line: the ATLIN is the best honing guide you can actually buy on Amazon; the Katz-Moses and Veritas Mk.II are premium direct-buy upgrades. It holds the angle, but you still strop off the wire edge. Pair it with our woodturning and hand-plane guides.
Frequently asked questions
What is the best sharpening jig for chisels and plane irons?
ATLIN Honing Guide. An upgraded Eclipse-style side-clamp guide with a hardened steel roller that will not develop flat spots, and it covers the widths that matter, chisels from 1/8 to 1-7/8 inch and plane irons from 1-3/8 to 3-1/8 inch, with separate jaw positions for low-angle and high-angle tools.
What should you look for in sharpening jig for chisels and plane irons?
Focus on angle range, roller type, width limits, and it only hones the bevel.
What is a good alternative to the ATLIN Honing Guide?
The the Katz-Moses Universal Sharpening Jig. Clamps virtually any width and handles skewed and straight blades without add-ons, with built-in angle shelves and a magnetic fence. It is sold on kmtools.com, not Amazon, and costs more than the ATLIN.
